| General Specifications | bizhub 224e |
| Type | Desktop Printer / Copier / Scanner |
| Resolution Scan | Main: 600dpi × Sub: 600dpi |
| Resolution Print | 1,800 dpi (equivalent) × 600 dpi |
| Gradation | 256 |
| Memory Capacity (Std./Max.) | 2 GB/4 GB |
| HDD | 250 GB |
| Original Type | Sheets, Books, Objects |
| Max. Original Size | A3 (11″ × 17″) |
| Warm-Up Time3 (23°C, std. voltage) | 26 sec. or less |
| First Copy Out Time4 | 22 sec. or less |
| Copy Speed (A4 Crosswise) | 22 ppm |
| Zoom | 29 to 400% (in 0.1% increments) |
| Paper Capacity(80g/m2) | Tray 1 : 500 sheets (up to A3), Tray 2 : 500 sheets (up to SRA3), Multiple Bypass Tray : 150 sheets (up to SRA3) |
| Max. Paper Capacity (80g/m2) | 3,650 sheets |
| Paper Weight | Tray 1 / 2 : 52 to 256 g/m2, Multiple Bypass Tray : 60 to 300 g/m6 |
| Multiple Copy | 5 to 9,999 sheets |
| Auto Duplex | Standar |
| Auto Duplex Paper Weight | 52 to 256 g/m2 |
| Power Requirements | AC220 to 240 V 8 A (50 to 60 Hz) |
| Max. Power Consumption | 1.58 kW or less |
| Dimensions [W] × [D] × [H] | 617 × 685 × 771 mm (24-1/4″ × 27-1/2″ × 30-1/2″) |
| Weight | Approx. 76.5 kg (168-3/4 lb) |
| Space Requirements5 [W] × [D] | 939 × 1,214 mm (37″ × 47-3/4″) |
| Print Specifications | |
| Type | Embedded |
| CPU | SOC 800Mhz(DualCore) |
| Memory | Shared with the copier |
| Print Speed | Same as Copy Speed (when using the same original) |
| HDD | 254 GB (Shared witd tde copier) |
| Print Resolution | 1,800 dpi (equivalent) × 600 dpi (at smoothing) or 1,200 dpi × 1,200 dpi (in 1,200 dpi mode) |
| PDL | PCL5e/c Emulation, PCL6 (XL Ver. 3.0) Emulation, PostScript3 (3016) Emulation, XPS (Ver.1.0) |
| Protocol | TCP/IP, IPX/SPX (NDS support), SMB (NetBEUI), LPD, IPP1.1, SNMP, HTTP |
| Support OS | Windows XP SP2 / XP SP2 64bit / Vista / Vista 64bit / 7 / 7 64bit /8 / 8 64bit Windows Server 2003 / Server 2003 64bit / Server 2003 R2 / Server 2003 R2 64bit / Server 2008 / Server 2008 64bit / Server 2008 R2 / Server 2012 Mac OS 9.2 / X 10.2 / X 10.3 / X 10.4 / X 10.5 / X 10.6 / X 10.7 / X 10.8 Linux |
| Interface | Ethernet (10BASE-T/100BASE-TX/1000BASE-T), USB 1.1, USB 2.0, USB Host |
| Scanning Specifications | |
| Type | Full-Colour Scanner |
| Interface | Ethernet (10BASE-T/100BASE-TX/1000BASE-T) |
| Driver | TWAIN Driver, HDD TWAIN Driver |
| Protocol | TCP/IP (FTP, SMB, SMTP, WebDAV) (IPv4/IPv6) |
| Scanning Speed (Colour/B&W) | Simplex: 80 opm |
| (300 dpi, A4 Crosswise) | Duplex: 160 opm |
| Max. A3 (11″ × 17″) |
| Output Format | TIFF, JPEG, PDF, Compact PDF, XPS, Compact XPS, OOXML (pptx, xlsx*, docx*), Searchable PDF*, PDF/A, Linearised PDF *Optional |
| Scanning Resolution Push | 200dpi / 300dpi / 400dpi / 600dpi |
| Scanning Resolution Pull | 100dpi / 200dpi / 300dpi / 400dpi / 600dpi |
| Main Functions | Scan to E-Mail, Scan to FTP, Scan to BOX (HDD), Scan to PC (SMB), Network TWAIN, Scan to WebDAV, Scan to Me, Scan to Home, Scan to USB, Scan to Scan Server, Scan to Web Service (WSD-Scan), Device Profile for Web Services (DPWS) |
| Other Functions | Multi-Method Send, Authentication at the time of E-Mail send (SMTP authentication, POP before SMTP), S/MIME, Annotation |
| Internet Fax | |
| Protocol | SMTP, POP |
| Connection Mode | Full-Mode |
| Sending Paper Size | A3, B4, A8 |
| Recording Paper Size | Max. A7 |
| Resolution | 204 × 100 dpi, 200 × 200 dpi, 400 × 400 dpi, 600 × 600 dpi |
| Interface | Ethernet (10BASE-T/100BASE-TX/1000BASE-T) |
| Colour | Support Colour Internet Fax |
| Format | Send: TIFF-F, Receive: TIFF-F ,Colour/Grey Scale: TIFF (RFC3949 Profile-C) |
| Fax Kit FK-511 (Optional) | |
| Communication | Super G7 |
| Compatible Lines | Public Switch Telephone Network, Private Branch Exchange, Fax Communication Line |
| Line Density | G3 (8 dot/mm × 3.85 line/mm, 600 × 600 dpi) |
| Modem Speed | 2.4 to 33.6 kbps |
| Compression | MH/MR/MMR/JBIG |
| Sending Paper Size | Max. A3 (Long Lengtd Support: Max.1,000 mm) |
| Recording Paper Size | Max. A3 (Long Lengtd Max. 1,000 mm — following the page division —) |
| Transmission Speed | Less than 3 sec. (A4, V.34, 33.6 kbps, JBIG) |
| Memory | Shared witd the copier |
| Number of Abbr. Dials | 2 |
| Number of Program Dials | 400 |
| Number of Group Dials | 100 |
| Sequential Multiple Station Transmission | Max. 604 |
